48 HMX6803+ and OP+HMX+ Installation and Operation Manual
Copyright © 2009, Harris Corporation
Chapter 3: Operation
Input > Audio >Status
Input AES (1A–8B)
Status
Reports the current status
of the specified audio input
channel
•Normal
• Silence
• Peak
•Not Present
Input > Metadata
Embedded Metadata
Present
Reports the presence of
embedded metadata
•No
•Yes
External Metadata
Present
Reports the presence of
external metadata
•No
•Yes
Input > AFD / VI / WSS De-embedder
AFD Present Indicates the presence of
AFD packets
•None
•UNDEF
• RSVD
• 16:9 top
• 14:9 top
• >16:9 in 4:3
• 4:3 full
•16:9 l
•14:9 l
•4:3 a 14:9
• 16:9 l a 14:9
• 16:9 l a 4:3
• 16:9 full
• 14:9 cntr
• >16:9 in 16:9
• 16:9 full
•4:3 p
• 16:9 prtctd
• 14:9 p
• 4:3 p a 14:9
• 16:9 a 14:9
• 16:9 a 4:3
VI Scan Present Indicates the presence of
VI packet Scan Part
(526/625 only)
•None
•NO INFO
• 525 4:3
• 625 4:3
•RSVD
• 525 16:9
• 625 16:9
VI AFD Present Indicates the presence of
VI packet AFD Part
(526/625 only)
•None
•UNDEF
• RSVD
• 16:9 top
• 14:9 top
• >16:9 in 4:3
• 4:3 full
•16:9 l
•14:9 l
•4:3 a 14:9
• 16:9 l a 14:9
• 16:9 l a 4:3
• 16:9 full
• 14:9 cntr
• >16:9 in 16:9
• 16:9 full
•4:3 p
• 16:9 prtctd
• 14:9 p
• 4:3 p a 14:9
• 16:9 a 14:9
• 16:9 a 4:3
Table 3-10. HMX6803+ and OP+HMX+ Parameters (Continued)
Path Parameter Name
Bank/
Switch
Function Options or User Range
