HMX6803+ and OP+HMX+ Installation and Operation Manual 17
Copyright © 2009, Harris Corporation
Chapter 2: Installation
Maximum 6800+ Frame Power Ratings
See the FR6802+ Frame Installation and Operation Manual for information
about installing and operating an FR6822+, FR6802+QXF or FR6802+ frame
and its components.
Before installing this product, read the 6800+ Series Safety
Instructions and Standards Manual shipped with every 6800+ Frame
Installation and Operation Manual or downloadable from our website.
This safety manual contains important information about the safe
installation and operation of 6800+ series products.
The power consumption for the HMX6803+ and OP+HMX+ modules is 12 W.
Table 2-3 describes the maximum allowable power ratings for 6800+ frames.
Note the given maximums before installing any 6800+ modules in your frame.
HMX6803+ and OP+HMX+ modules operate only in fan-cooled FR6802+ and
FR6822+ frames, subject to the limitations shown in
Table 2-3. These modules
cannot be installed in 6800/7000 series frames.
To maintain proper temperatures, ensure that the front panel is closed at all
times and that the fan module is fully operational.
Table 2-3. Maximum Power Ratings for 6800+ Frames
6800+ Frame Type
Max. Frame
Power
Dissipation
Number of
Usable
Slots
Max. Power
Dissipation
Per Slot
FR6802+XF
(frame with AC power supply)
120 W 20 6 W
FR6802+XF48
(frame with DC power supply)
105 W 20 5.25 W
FR6802+QXF frame
(with AC or DC power supply)
120W 20 6 W
FR6822+ frame (with AC or DC power supply) 120W 20 6 W
