Chapter 3
Operation
Operating Notes
When you set the control parameters on the HMX6803+ and OP+HMX+,
observe the following:
• If you make changes to certain parameters, other related parameters may
also be affected. See “Cross-Functional Parameter Changes” on page 38 for
more information.
• When you change a parameter, the effect is immediate. However, the
module requires up to 30 seconds to save the latest change. After 30
seconds, the new settings are saved and will be restored if the module loses
power and must be restarted.
Q-SEE Compliant Thumbnails
When installed in an FR6802+QXF or FR6822+ frame that also contains a
6800+ETH resource module, HMX6803+ and OP+HMX+ module control
windows have an extra Streaming tab in CCS Pilot and Navigator (version
3.2.1 or later). There you can view output video from the module.
In addition, video from the HMX6803+ and OP+HMX+, displayed at up to
three frames per second, can be displayed on the 6800+ETH’s control page, and
(for CCS Navigator only) on Graphical Navigation pages.
Note
HMX6803+ and OP+HMX+ modules all show a HMX6803+ label in
Navigator.
Thumbnail streaming is not supported for the following video standards:
• 1080i 60
• 720p 60
• 1080p 24/25/29.97/30
• 1080psF 23.98/24
• 1080p 50/59.94/60
