HMX6803+ and OP+HMX+ Installation and Operation Manual 41
Copyright © 2009, Harris Corporation
Chapter 3: Operation
Table 3-8. Parameter Availability Based on Operating Mode
Condition Available Parameters Unavailable Parameters
1080i/p/psf and
720p 3G or 1.5G
HD Operating
Mode
• Y CRC Error Counter
• Y CRC Error Counter Clear
• C CRC Error Counter
• C CRC Error Counter Clear
• EDH Present
• EDH Error Counter
• EDH Error Counter
Clear
• VI Detect Line Fld1
• VI Detect Line Fld2
• VI AFD Present
• VI Scan Present
• Out Aspect Ratio
• VI Control
• VI Embed Line
• VI Select
• SD Out VI with AFD
• VI Output (AFD)
• VI Output (Scan)
• WSS Detect Line
• WSS Present
• WSS Control
• WSS Embed Line
• WSS Select
• WSS Output
SDI 525i 59.94
Operating Mode
• EDH Present
• EDH Error
Counter
• EDH Error
Counter Clear
• VI Detect Line
Fld1
• VI Detect Line
Fld2
• VI AFD Present
• VI Scan Present
• Out Aspect Ratio
• VI Control
• VI Embed Line
• VI Select
• SD Out VI with AFD
•VI Output (AFD)
• VI Output (Scan)
• Y CRC Error
Counter
• Y CRC Error
Counter Clear
• C CRC Error
Counter
• C CRC Error
Counter Clear
• WSS Detect Line
• WSS Present
• WSS Control
• WSS Embed Line
• WSS Select
• WSS Output
SDI 625i 50
Operating Mode
• EDH Present
• EDH Error
Counter
• EDH Error
Counter Clear
• VI Detect Line
Fld1
• VI Detect Line
Fld2
• VI AFD Present
• VI Scan Present
• Out Aspect Ratio
• VI Control
• VI Embed Line
• VI Select
• SD Out VI with AFD
•VI Output (AFD)
• VI Output (Scan)
• WSS Detect Line
• WSS Present
•WSS Control
• WSS Embed Line
• WSS Select
•WSS Output
• Y CRC Error Counter
• Y CRC Error Counter Clear
• C CRC Error Counter
• C CRC Error Counter Clear
