76 HMX6803+ and OP+HMX+ Installation and Operation Manual
Copyright © 2009, Harris Corporation
Appendix A: Audio Bit Manipulation
10 to 13 0 to 7 Alphanumeric channel destination data S Y
• RX ignores bits
• TX passed bits
unmodified
14 to 17 0 to 7 Local sample address code S Y
• RX ignores bits
• TX passed bits
unmodified
18 to 21 0 to 7 Time-of-day sample address code S Y
• RX ignores bits
• TX passed bits
unmodified
22 0 to 3 Reserved N Y
• RX ignores bits
• TX passed bits
unmodified
22 4 Bytes 0 to 5 reliability flag N Y
• RX ignores bits
• TX passed bits
unmodified
22 5 Bytes 6 to 13 reliability flag S Y
• RX ignores bits
• TX passed bits
unmodified
22 6 Bytes 14 to 17 reliability flag S Y
• RX ignores bits
• TX passed bits
unmodified
22 7 Bytes 17 to 21 reliability flag S Y
• RX ignores bits
• TX passed bits
unmodified
23 0 to 7 CRC Y Y
• RX ignores bits
• TX calculates CRC on
output
Table A-2. Channel Status (C-Bits) Data Description (Continued)
Byte Bit Function RX TX Remarks
