11
Some buttons have a toggle function, the ON.OFF button has a quick
‘click’ action as well as a longer (half-second) ‘press’ action and the shutter
release has two positions: ‘half-press’ and ‘full-press’.
Several buttons on the grip are multifunctional, according to the state of
the menu. In the example illustrated here, the FLASH button functions as
the EXIT button, the AF button functions as the ON button and the ISO/
WB button functions as the SAVE button.
The front and rear control wheels can also be used to navigate the menu
on the digital capture unit.
At very low temperatures the displays require a few seconds to present new
settings.
The control wheels are also used to navigate the menu on the digital capture
unit.
The FLASH button also acts as an EXIT button and the ISO/WB button
acts as an OK button when navigating the digital capture unit menu.
The following is a list of the various terms describing the various
actions that appear in the menu (on the grip display):
Enter : moves screen down one level on the menu.
Exit : moves screen back up one level on the menu. Does not save any
settings.
O : deactivates the particular function being set.
On : activates the particular function being set.
Sel. : (Select) - selects the character marked for image info and profile
name
ESC : (Escape) - terminates an action and returns to the main screen.
Does not save any settings.
Save : saves a setting and also moves screen back up one level on the
menu. Can save many changes made in a setting sequence.
Examples
Remember the following groupings of ‘saved’ and ‘not-saved’ actions when making settings changes:
SAVED NOT SAVED
‘Quick save’ - half-press shutter release button
Save - press save button (ISO/WB button)
Escape - press ESC button (PROFILES /ESC button)
Exit - press exit button (FLASH button)
The basic principle behind making changes is that the appropriate button is rst
pressed to access the menu and then settings altered by way of the control wheels.
The appropriate control wheel is designated by arrowheads alongside the setting
description.
