Hasselblad H5D User Manual

16
SHORTCUT ACCESS TO
BUTTON SETTING SCREENS
1) Press the MENU button fol-
lowed by the button you want
to reassign (True Focus, AE-L,
M.UP or Stop Down).
This directly accesses the par-
ticular button you chose at the
Custom options level in the
menu.
2) Rotate the REAR scroll wheel to
select the function you want the
button to activate.
3) Press SAVE (or the shutter release
button). The selected button will
now activate the newly assigned
function directly.
These four grip buttons by de-
fault are assigned according to
name but can be reassigned (in
Custom Options #4, #5, #6 and
#7 or by using the Camera Con-
guration toolin Phocus) to var-
ious other functions listed here.
(See also the two customizable buttons on the
sensor unit: P1 and P2. These are set on the sen-
sor unit or in the Camera Conguration tool in
Phocus).
1
True Focus
2
AE-L
3
M.UP
4
STOP DOWN
· True Focus
Temporarily activates True Focus
function.
· AE-lock
Temporarily locks a light reading
in auto or manual modes. Also
used in Zone metering.
· Mirror up
Locks mirror up for vibration
reduced captures. Also lowers
mirror.
· Stop down
Activates stop down function for
depth-of-eld checking.
· AF
Temporarily activates Autofocus
function.
· Self timer
Sets self timer mode. Provides
a timed remote shutter release
function with the option of a
change in sequence of the mirror
movement (to reduce vibration).
· Bracketing
Sets Bracketing mode. This func-
tion provides an automatic series
of captures; one at the standard
exposure setting (Manual or
Auto) and the others with prede-
termined deviations in EV from
the standard exposure.
· B mode
Sets B mode shutter setting.
Shutter stays open as long a
pressure is maintained on shut-
ter release button.
· T mode
Sets T mode shutter setting.
Shutter stays open after rst
press of shutter release button
(toggle function to close again).
· Flash Measure
Activates manual ash measure
function.
· Interval timer
Activates interval function start
screen.
· Cycle Light Meter mode
Selects next light metering mode.
· Expose
Provides alternative to shutter
release button.
· Display O
Activates Display O mode im-
mediately.
· Histogram
Provides a histogram on the grip
display for the last capture.
SAVE
(ISO/WB button)
MENU
Rear scroll
wheel
REASSIGNABLE GRIP BUTTONS  FUNCTION OPTIONS
· Focus Conf.
Provides a 100% preview on
display for focus checking.
Not available for True Focus and
AE-L buttons.
· Delete
Direct access to delete dialogue.
· Grey balance exp.
Provides selective capture for
grey balance calculations.
· Spirit Level
Activates spirit level on back (but
not in viewnder).
· Rear Info Screen
Activates grip information on
sensor unit display.
Tip
See separate section about the
Camera Conguration tool.
1
2
3
4

Hasselblad H5D Specifications

General

Sensor Type	CCD
ISO Range	50-800
Lens Mount	Hasselblad H Mount
Resolution	50 megapixels
Shutter Speed	1/800 sec to 32 sec
Viewfinder	Interchangeable waist-level or eye-level viewfinder
Display	3.0-inch TFT LCD
Storage Media	CompactFlash (CF) card
Battery	Li-ion Battery
Image Format	RAW
LCD Screen	3.0-inch TFT LCD
Dimensions	153 x 131 x 205 mm
Weight	2290 g
