Hasselblad H5D User Manual

39
1. Press MENU button on grip and select Settings or press MENU twice.
2. Select Custom Options and select #31 (True Focus in AF-S) with the Front
scroll wheel. Select ON with the Rear scroll wheel. Save.
3. Aim camera at important area in subject and half-press the shutter release
button.
4. Wait for the True Focus icon to appear (in the viewnder) and the audio con-
rmation signal.
5. Maintain the half-press and recompose the picture. Press fully to capture.
The True Focus icon disappears from the viewnder. True Focus function is
retained.
1. Press MENU button on grip and select Settings or press MENU twice.
2. Select Custom Options and the desired button to reassign with the Front
scroll wheel (M.UP button in this example). Select True Focus with the Rear
scroll wheel. Save.
2. Aim camera at important area in subject and press the selected button (the
grip display now indicates AF-T mode).
3. Wait for the True Focus icon to appear (in the viewnder) and the audio con-
rmation signal.
4. Recompose the picture and press shutter release button (camera does not re-
focus because it is temporarily in AF-T mode). The True Focus icon disappears
from the viewnder. Camera reverts to AF-S.
Note that camera reverts to AF-S if the focusing ring on the lens is moved.
TEMPORARILY ACTIVATED BY A SELECTED CUSTOMIZABLE BUTTON  AUTOFOCUS RETAINED
MENU > SETTINGS > CUSTOM OPTIONS
In this mode the True Focus function is activated by pressing an assigned button. This produces a ‘one-shot’ setting where
the camera reverts to its original Autofocus setting after capture. Useful if you want to quickly switch back and forth be-
tween True Focus and normal Autofocus. Works with or without a Custom Options #31 setting.
FOUR TRUE FOCUS METHODS
1
/2 !
ACTIVATED BY SHUTTER RELEASE BUTTON  TRUE FOCUS RETAINED
MENU > SETTINGS > CUSTOM OPTIONS > # 31
In this mode the autofocus function is eectively converted into the True Focus function. That is, focus is set by half-pressing
the shutter release button. Remember, though, that the True Focus function is retained until turned o in Custom Options.
SAVE
MENU
Front scroll
wheel
Rear
scroll
wheel
MENU
Front scroll
wheel
SAVE
Rear
scroll
wheel

Hasselblad H5D Specifications

General

Sensor Type	CCD
ISO Range	50-800
Lens Mount	Hasselblad H Mount
Resolution	50 megapixels
Shutter Speed	1/800 sec to 32 sec
Viewfinder	Interchangeable waist-level or eye-level viewfinder
Display	3.0-inch TFT LCD
Storage Media	CompactFlash (CF) card
Battery	Li-ion Battery
Image Format	RAW
LCD Screen	3.0-inch TFT LCD
Dimensions	153 x 131 x 205 mm
Weight	2290 g
