Hasselblad H5D User Manual

89

USING PROFILES
1) From the main screen, click PROFILES on the grip and the
prole screen will appear.
2) Use the scroll bar to go through the list and highlight the
desired prole.
3) Press Load (AF button). The camera is now set according to
all the parameters stored according to the name.

CHANGING A PROFILE NAME
You can change a prole name (except ‘Default’) at any time.
1) From the main screen, click PROFILES (ON.OFF button)
on the grip and the prole screen will appear.
2) Scroll through the list (front or rear scroll wheels) and
highlight the desired prole.
3) Press Load (AF button).
4) Click PROFILES (ON.OFF button) again.
5) Press Save (ISO/WB button) The Prole name screen is
then displayed where you can rename the prole to what
suits you (see under Image Info 4.2).
SAVE
AF
PROFILES
Tip
To quickly reset all proles back to the original factory settings:
1. Remove battery.
2. Wait 5–10 seconds.
3. Replace the battery while keeping both the Menu and IS0/
WB buttons pressed.
Tip
Proles and prole creation can be handled in Phocus in a very
intuitive way. The Camera Conguration is found in the menu:
Window – Camera Conguration...

Hasselblad H5D Specifications

General

Sensor Type	CCD
ISO Range	50-800
Lens Mount	Hasselblad H Mount
Resolution	50 megapixels
Shutter Speed	1/800 sec to 32 sec
Viewfinder	Interchangeable waist-level or eye-level viewfinder
Display	3.0-inch TFT LCD
Storage Media	CompactFlash (CF) card
Battery	Li-ion Battery
Image Format	RAW
LCD Screen	3.0-inch TFT LCD
Dimensions	153 x 131 x 205 mm
Weight	2290 g
