Hasselblad H5D User Manual

18
Some buttons access shortcuts if used in dierent ways or contexts.
1
Menu button – P1 / P2 setting option access
Press MENU on sensor unit and then P1 or P2 to
access the relevant setting options directly for that
particular button. After making any changes, press
EXIT (Menu button) or the shutter release button to
save the new setting.
2
DISPLAY button – Display
Press and hold to return to default preview display
mode.
3
Shutter release button – Camera activation
Re-activates camera from Display O mode.
4
Shutter release button – Quick save
Half-press shutter release button to make a quick save
when making settings adjustments.
5
Front scroll wheel – Menu navigator / Browser
Functions as a horizontal navigator on sensor unit
menu as well as a capture browser in Browse mode.
6
Menu button – Custom Options access
Press MENU button twice on the grip to access the lat-
est setting made in Custom Options. After making any
changes, press the shutter release button to save the new
setting.
7
Menu button – Customizable Button access
Press MENU on the grip and then the desired custom-
izable button (True Focus, AE-L, M.UP, Stop Down)
to access the choices available in Custom Options.
After making any changes, press SAVE or the shutter
release button to save the new setting.
8
Proles button – Camera activation
Re-activates camera from Display O mode.
9
Rear scroll wheel – Menu navigator
Functions as a vertical navigator on sensor unit menu.
10
True Focus button – Camera activation
Re-activates camera from Display O mode.
11
True Focus button – Zoom-in button
Automatically acts as Zoom-in button when in
Browse mode.
12
True Focus button – Selection button
Automatically acts as value selector on sensor unit
menu when in Menu mode.
13
CF Card format button – CF card format
Formats the current inserted CF card (requires
conrmation).
14
AE-L button – Camera activation
Re-activates camera from Display O mode.
15
AE-L button – Zoom-out button
Automatically acts as zoom-in button when in Browse
mode.
16
AE-L button – Selection button
Automatically acts as value selector on sensor unit
menu when in Menu mode.
17
Mirror Up button – Camera activation
Re-activates camera from Display O mode.
18
Stop Down button – Camera activation
Re-activates camera from Display O mode.
3 4
5
6 7
8
9
SHORTCUTS
2
1
12
11
10
13
15 1614
17
18

Hasselblad H5D Specifications

General

Sensor Type	CCD
ISO Range	50-800
Lens Mount	Hasselblad H Mount
Resolution	50 megapixels
Shutter Speed	1/800 sec to 32 sec
Viewfinder	Interchangeable waist-level or eye-level viewfinder
Display	3.0-inch TFT LCD
Storage Media	CompactFlash (CF) card
Battery	Li-ion Battery
Image Format	RAW
LCD Screen	3.0-inch TFT LCD
Dimensions	153 x 131 x 205 mm
Weight	2290 g
