Hasselblad H5D User Manual

74
Mirror sequence highlighted.
‘Delay rst, then mirror raised’
chosen as option.
‘Delay’ highlighted with drop
shadow. 10 seconds chosen.
SELF TIMER SETTING
1) Press MENU on grip.
2) Turn Front scroll wheel until Self Timer appears.
3) Press ENTER.
4) Turn Front scroll wheel to access the options, that are:
Delay
Mirror sequence
Mirror Up / Mirror Goes Down
(A drop shadow will be displayed beneath the selected sym-
bol, for example )
5) When Delay is highlighted – – turn the Rear scroll
wheel to choose a delay range from 2 - 60s in 1s inter-
vals.
6) Turn the Front scroll wheel again to choose Delay /
Mirror Up, Mirror Up/ Delay sequence – . When
highlighted turn the Rear scroll wheel to choose.
Delay / Mirror Up sequence =
Delay for set amount of time – mirror raised – cap-
ture made.
Mirror Up/ Delay sequence =
Mirror raised – delay for set amount of time – cap-
ture made.
7) Turn the Front scroll wheel again for
Mirror goes down / Mirror remains up – –
choice. Turn the Rear scroll wheel to choose.
Mirror goes down =
Mirror returns to its normal position and the camera
is made ready for the next capture.
Mirror raised =
Mirror remains in raised position. No image is visible
in the viewnder until M UP button pressed.
8) Press On. Note that this now reads O and the line of
text at the bottom of the screen reads ‘Self timer on’.
9) Press SAVE.
10) Press ENTER again from the Self Timer screen to acti-
vate the function.
11) Press On.
12) Half-press the shutter release button to standby mode
for this function (press the shutter release button again
(full press) for activation) or full-press the shutter release
for immediate activation.
MENU
ON
Front scroll
wheel
ENTER
or
SAVE
Rear scroll
wheel
Mirror down /up highlighted.
‘Mirror down after capture’
chosen as option.
Note
You can halt the sequence by
clicking the ON / OFF ( ESC)
button.
Tip
Press the Mirror Up button
twice within 0.5s to access the
self timer mode directly.
– continued
Tip
Check the lower text-row
on the screen for ON or OFF
status.

Hasselblad H5D Specifications

General

Sensor Type	CCD
ISO Range	50-800
Lens Mount	Hasselblad H Mount
Resolution	50 megapixels
Shutter Speed	1/800 sec to 32 sec
Viewfinder	Interchangeable waist-level or eye-level viewfinder
Display	3.0-inch TFT LCD
Storage Media	CompactFlash (CF) card
Battery	Li-ion Battery
Image Format	RAW
LCD Screen	3.0-inch TFT LCD
Dimensions	153 x 131 x 205 mm
Weight	2290 g
