HBM C6A - Page 24

C6A
24
A0638−2.3 en/de/frHBM
Load button ZL (for high−precision measurement)
for nominal forces in range 200 kN − 2 MN
for 5 MN nominal forces
R sphere radius
R sphere radius
M12; 15 deep
M8; 15 deep
Nominal
force
Dimensions in mm
ZL
Order no.
Weight in
kg
g H
−0.1
J R U
−0.2
b c
d
200 kN 1-C6/20T/ZL 0.8 60 31.9 M5 300 32 45 5 30
500 kN 1-C6/50T/ZL 0.8 60 31.9 M5 300 44 45 5 30
1 MN 1-C6/100T/ZL 6.4 120 67.9 M6 600 64 80 8 60
2 MN 1-C6/200T/ZL 6.8 120 67.9 M6 600 85 80 8 60
5 MN 1-C6/200T/ZL 6.5 − − − − 129.8
−0.05
60 35
