HBS CDM 3201 - Further Instructions

CDM 3201 Order No. BA 92-12-3321A Issue 19.09.08 83
Further Instructions
Welding elements, abbreviations, materials, standards, mechanical
properties to actual standards
Abbrev iations
for studs
Mat er ial
Mate rial
international
name
Norm
Mechanical
characteristics
Steel (S235)
4.8
1)
copper plated
Mild steel ISO 898-1 See ISO 898-1
Stainless steel
AISI 304/305
Brass
EN A W-
Al99,5
Aluminum
99,5
EN 573-3 R
m
≥
100 N/mm
2
A
luminum
AlMg3
EN A W-
AlMg3
EN 12301-2 R
m
≥
230 N/mm
2
1.4301/03
(A2-50)
ISO 3506-1 ISO 3506-1
CuZn3 7
(Ms63)
EN 12166 R
m
≥
370 N/mm
2
IT
Stud w ith internal
thread
Stud types
Threaded stud PT
Pin
(Unthreaded stud)
UT
Stud w elding w ith
capacitor
discharge (TS)
Further materials on request
1)
weldable
Prestress at installation (tie load) and torque
Threaded
stud
Pr es t r es s
at installation
(kN)
Tor que
(Nm)
Pr es t r es s
at installation
(kN)
Torque
(Nm)
Prestress
at installation
(kN)
Torque
(Nm)
Prestress
at installation
(kN)
Torque
(Nm)
M 3 1,1 0,8 0,7 0,5 0,5 0,4 0,8 0,6
M 4 1,8 1,8 1,1 1,1 1,0 0,9 1,4 1,3
M 5 3,0 3,6 1,9 2,3 1,6 1,9 2,3 2,7
M 6 4,3 6,1 2,7 3,8 2,2 3,1 3,2 4,5
M 8 8,0 15,0 4,9 9,5 4,0 7,5 6,0 11,0
M 10 13,0 30,0 7,8 19,0
Steel (S235) 4.8
1)
µ = 0,18
R
p0,2
= 340 N/mm
2
1.4301/03 (A2-50)
µ = 0,18
R
p0,2
= 210 N/mm
2
AlMg3 (F23)
µ = 0,18
R
p0,2
= 170 N/mm
2
CuZn37 (Ms63)
µ = 0,18
R
p0,2
= 250 N/mm
2
Values correspond with actual standards
1)
weldable
All given values are leads for minimum tensile strength and minimum torque of a weld without permanent deformation
of parts to be joined. Parts to be joined must have sufficient wall thickness. Values apply for cold rolled threaded studs
with standard thread without surface protection and without thread lubrication. Throughout the entire stud length, at
least the stressed cross section must be present. Values apply for indicated yield strengths.
Material combinations
according to the actual standards (select stud material in a way that material of the
same kind is welded).
ISO/TR 15608
Groups 1 - 6, 11.1
ISO/TR 15608 Groups 1 - 6,
11.1 and galvanized and
metal plated steel sheets,
max. coating thickness
25 µm
ISO/TR
15608
Group 8
Copper and
unleaded
copper alloys,
e.g. CuZn37
(CW508L)
ISO/TR
15608
Groups 21
and 22
Steel (S235) 4.8
1)
abab --
1.4301/1.4303 a b a b --
CuZn37 b b b a --
EN AW-Al99,5 -- -- -- -- b
EN AW-AlMg3 -- -- -- -- a
-- non weldable
a well suited fo r any applicatio n, e.g. po wer transmissio n
b suitable, limitations with power transmission
Base material
Stud material
Exemplificatio n o f welding suitability:
Weldability tests of other material combinations upon request.
1)
weldable
Further Instructions
