5.6.9 Adjusting the Thyristor (Capacity Switch)
With this menu item, you can select the level of welding energy via the capacity switch
of the power unit.
Two levels are available (800 Ws and 2400 Ws).
Press the arrow key
until the sign ">" is displayed
in front of "Thyristor".
Gun Service
Reset >Thyristor
⇒ with the Enter key open menu item
"Thyristor“
⇒ with or select
"Thyristor 1“ or
THYRISTOR-Mode
>Thyristor 1
"Thyristor 1 + 2“
THYRISTOR-Mode
> Thyristor 1 + 2
With "Thyristor 1“ you select 800 Ws, with "Thyristor 1 + 2“ 2400 Ws are available.
