HBS CDM 3201 - Adjusting the Language; Adjusting the Lift Test (Welding Gun)

CDM 3201 Order No. BA 92-12-3321A Issue 19.09.08 39
5.6.5 Adjusting the Language
In the main menu, you can select the language which is shown in the text display.
Press the arrow key until the
sign ">" is shown to the left of "Language".
Autom. Mode
Control>Language
⇒ with the enter key open
the menu item "Language"
⇒ select "Language" with or
Setup
Language >english
Languages: English, German
5.6.6 Adjusting the Lift Test (Welding Gun)
In this menu item, you can test the functionality of your welding gun CA 08. During the
test, the welding gun is triggered as with normal welding sequence, but the welding
current is not released. A weld is not carried out.
Press the arrow key until
the sign ">" appears in front of "Gun".
Control Language
>Gun Service
⇒ open with enter key the menu
item "Gun"
Test Gun
z
██ -- -- -- ██
Now you can work as with standard
welding sequence, you can adjust
a lift at the welding gun greater
than zero, position the welding gun
onto the work piece and trigger it.
⇒ The welding gun lifts off.
5 Stud Welding Procedure
5.6 Switching on the Power Unit
