5.9.1 Error Codes
Error
number
Display Description Operator instructions
1 Rech. Rel. (Off) Recharge relay does not release Switch off the unit, switch on after approx. 5 minutes,
if error is still present, contact HBS service
2 Rech.Rel. (ON) Recharge relay does not attract Switch off the unit, switch on after approx. 5 minutes,
if error is still present, contact HBS service
3 Nom. value data Nominal value data not transferred Switch off the unit, switch on after approx. 5 minutes,
if error is still present, contact HBS service
4 (#04) --- ---
5 ! Not discharged ! Discharge of capacitor battery impossible Switch off the unit, switch on after approx. 5 minutes,
if error is still present, contact HBS service
6 Time-Out charging Charging time of capacitor battery too long Switch off the unit, switch on after approx. 5 minutes,
if error is still present, contact HBS service
7 Rech. transistor Recharging time of of capacitor battery too long Switch off the unit, switch on after approx. 5 minutes,
if error is still present, contact HBS service
8 (#08) --- ---
9 Charging control Charge-discharge control defective Switch off the unit, switch on after approx. 5 minutes,
if error is still present, contact HBS service
10 Time-Out weld. proc. Time-out during welding process Switch off the unit, switch on after approx. 5 minutes,
if error is still present, contact HBS service
11 Thyrist. def. PB Thyristor malfunction in buffer mode Switch off the unit, switch on after approx. 5 minutes,
if error is still present, contact HBS service
12 Thyrist. def. weld. Thyristor defect Switch off the unit, switch on after approx. 5 minutes,
if error is still present, contact HBS service
13 Key sticks Key of operating terminal sticks Trigger several times, if error is still present, contact HBS
service
14 Battery voltage Voltage buffer battery main board too low Switch off the unit, switch on after approx. 5 minutes,
if error is still present, contact HBS service
15 Unit temp. max Inner temperature of the power unit too high Switch off the unit, switch on after approx. 5 minutes,
if error is still present, contact HBS service
16 Fan control Fan control defective Switch off the unit, switch on after approx. 5 minutes,
if error is still present, contact HBS service
