CDM 3201 Order No. BA 92-12-3321A Issue 19.09.08 59
8.2 Spare Parts
Spare part list power unit type CDM 3201 (92-12-3321A)
When ordering spare parts, please indicate order number and type of power unit
Pos. Quantity Order No. Description
1 1 88-14-079 Bottom plate complete
2 1 80-30-230 Capacitor battery 1
3 1 88-13-881 Terminal plate complete
4 1 80-30-270 Control insert complete
5 1 80-10-0209 Label mat white
6 1 80-30-232 Capacitor battery 2
7 1 92-50-029 Adaptive control module
8 2 80-80-506 P.C. board
11 1 80-11-754 HBS logo small 37 x 28
15 1 80-50-565 Mains cable
30 1 88-10-547 Rail connection
32 1 80-70-382 Connection cable 1
34 1 80-70-383 Connection cable 2
38 2 80-10-159 Cap
67 1 88-17-297 Distance piece 50 x 25 x 25
69 1 88-17-296 Contact piece
71 1 80-10-0951 Cable clip
73 2 80-90-147 Spring washer 6 mm
75 2 80-90-354 Screw M6 x 10
77 2 80-90-134 Screw M6 x 35
79 1 88-17-549 Welding current connector
81 1 88-17-545 Welding current connector
84 1 88-10-126 Cover
86 1 88-10-127 Cover
87 1 80-10-0210 Label mat black
89 1 80-10-857 Handle A=300
96 5 80-90-150 Washer 8 mm
98 4 80-90-167 Cupal washer M8
102 2 80-90-202 Washer 5 mm
103 13 80-90-121 Spring washer 4 mm
8 Appendix
8.2 Spare Parts
