32 CDM 3201 Order No. BA 92-12-3321A Issue 19.09.08
LED's
If you are working with process sequence control, see section 5.6.4, then the LED’s
inform whether the PAF value is inside the tolerance range of the reference or not.
Green value inside of adjusted tolerance range
Red value out of adjusted tolerance range
Basic settings
You can set the machine according to your requirements. Call-up the main menu with
the Enter key . The following menu items are available:
– Automatic Setting air pressure time for VBZ and tappet
– Mode Selection between program and library mode
– Control Activation of process sequence control
– Language Selection of language
– Welding gun Lift test of drawn-arc welding gun
– Service Time and date setting
– Reset Reset to HBS standard settings
– Thyristor Capacity switch (CDM 2401/CDM 3201/SCD 3201))
– Gas Setting of gas pre-flow time (SCD 3201)
Basically, you select a menu item with the arrow key and then you open it with
the enter key . Confirmation of settings and quitting the menu item is also carried
out with the enter key .
5.6.1 Adjusting the Charging Voltage of Capacitors
Refer to the table in section 5.5 for the required charging voltage matching your
welding job.
Select the menu item charging voltage with the arrow key .
Set the charging voltage (LCD display) with the two arrow keys
( ) on the display.
P5 >150 V
5 Stud Welding Procedure
5.6 Switching on the Power Unit
