HDL KNX / EIB Switch Actuators

_____________________________________________________________________________________

Guangzhou Hedong Electronic Co.,Ltd (HDL)

www.hdlchina.com 13/58

Threshold lower

Y Y Y

Threshold middle

Y Y Y

Threshold upper

Y Y Y

Curtain --- --- ---

Blinds

UP/DOWN

Y Y Y

Blinds

Adjustment

Y Y Y

Logic --- --- ---

AND

Y Y Y

XOR

Y Y Y

GATE

Y Y Y

Heating

Actuator

--- --- ---

Voltage fail state

Y Y Y

Recovery

Y Y Y

Switch state

Response

Y Y Y

1bit/1byte

PWM control

Y Y Y

Forced position

Y Y Y

Table1: Database application overview.

Note: For each function and mode, can only be used alone,

but "ON/OFF delay" function can be used with “switch

actuator” mode and scene function .

3.2 Object/Association/Group address define

In following table, The objects is assigned to the some

function of the channel output pages, If active some

functions and the object will be valid.

One or more group

addresses can be assigned to a object. The association will

connect group addresses to the object.

Name type Max. number of

communication

objects

Max. number

of associations

Max .number

of group

addresses

Switch 4fold 16A M/R4.16.1 90 254 254

Switch 8fold 16A M/R8.16.1 170 254 254

Switch 12fold 16A M/R12.16.1 250 254 254

Table2: Overview the max. number of the objects, max.
