HDL KNX / EIB Switch Actuators
_____________________________________________________________________________________
Guangzhou Hedong Electronic Co.,Ltd (HDL)
www.hdlchina.com 52/58
5.4 Blinds
The blinds function need two channels for driver, the first
channel control blinds UP, and the second channel control
blinds DOWN.
In the above combination. If start running the blinds UP,then
channel A switching ON and the channel B switching OFF.
If start running the blinds DOWN, then channel B switching
ON and the channel A switching OFF.
when running time out, the channel A and the Channel B will
switch OFF together.
UP/Adjustment : A→ON
B→OFF
DOWN/Adjustment : A→OFF
B→ON
Stop : A→OFF
B→OFF
Other combinations are similar to the here.
TOP
Bottom
UP
Down
Channel A
Channel B
