HDL M/R4.16.1 User Manual

HDL KNX / EIB Switch Actuators
_____________________________________________________________________________________
Guangzhou Hedong Electronic Co.,Ltd (HDL)
www.hdlchina.com 33/58
ON
OFF
Unchange: The channel switch position no change.
ON: The channel switch position set to ON.
OFF: The channel switch position set to OFF
---{Input object value>upper threshold}
If the value of receiving telegram from bus more than the upper
threshold value, the switch will action according to below option ( ON
or OFF or no action)
Options: Unchange
ON
OFF
Unchange: The channel switch position no change.
ON: The channel switch position set to ON.
OFF: The channel switch position set to OFF
3.5.6 Channel function “blinds”
Fig12: Blinds function windows
