HDL M/R4.16.1 User Manual

HDL KNX / EIB Switch Actuators
_____________________________________________________________________________________
Guangzhou Hedong Electronic Co.,Ltd (HDL)
www.hdlchina.com 53/58
5.5 Logic function
Logic function include two logic blocks in side. Both of logic block 1 and
2 allow select “AND”, “OR”, “XOR”, “GATE” logic by user
Note: N=channel A.B.C…
Con1=Logic connection1
Con2=Logic connection2
AND GATE
N L R
0 0 0
0 1 0
1 0 0
1 1 1
N L R
0 1 0
1 1 1
1 0 1
0 0 1
0 1 0
0 0 0
1 0 0
1 1 1
