4.2.3 Objects “Alarm for ON time out”
NO. Object name Function Flags Data type
13
Output N Alarm for ON time
out
C R T EIS1
DPT 1.005
1bit
This communication object is used for alarm when ON time out set range.
Table 7 Alarm statistics ON time (1bit)
4.2.4 Objects “R/W statistics counter”
NO. Object name Function Flags Data type
14
Output N Read/write
statistics for
counter
C R W T U DPT 12.001
4bytes
This communication object is used for statistics ON counter of the channel “N”. it can be
read/wrote via bus by setting this function activity
Table 8 Read/write statistics ON counter (4bytes)
4.2.5 Objects “Alarm for ON counter out”
NO. Object name Function Flags Data type
15
Output N Alarm for ON
counter out
C R T EIS1
DPT 1.005
1bit
This communication object is used for alarm when ON counter out set range.
Table 9 Alarm statistics ON counter (1bit)
4.2.6 Objects “Flashing”
NO. Object name Function Flags Data type
16
Output N Flashing C W U EIS1
DPT 1.001
1bit
This communication object is used for start or stop switch flashing.
Table 10 Flashing
