4.2.10 Objects “Scene”
NO. Object name Function Flags Data type
20
Output N Scene(8bit) C W U EIS14
DPT 18.001
1byte
This communication object is used to control the scene. The scene control see following
explain:
Telegram value:
C: 0-Call scene
1-Store scene(If scene allocated and the scene is the
current switch state)
R: Reserved
N: Scene NO.(bin:000000…111111=NO.1…64)
e.g: Hexadecimal
00h------call scene 1 (If scene allocated)
01h------call scene 2 (If scene allocated)
3Fh------call scene 64 (If scene allocated)
80h------store scene 1 (If scene allocated)
81h------store scene 2 (If scene allocated)
BFh------store scene 64 (If scene allocated)
C RNNNNNN
Table 14 Scene(8bits)
