HDL KNX / EIB Switch Actuators
_____________________________________________________________________________________
Guangzhou Hedong Electronic Co.,Ltd (HDL)
www.hdlchina.com 36/58
This logic block allow select as “AND” or “OR” or “XOR” or “GATE”
for Boolean calculation by user
Options: AND
OR
XOR
GATE
AND: Boolean calculation according to “AND” rule
OR: Boolean calculation according to “OR” rule
XOR: Boolean calculation according to “XOR” rule
GATE: “N” pass through logic block1 to logic block 2 by the
value of “Con1” set to 1 .
“N” cannot pass through logic block1 to logic block 2 until the
value of “Con1” is setting to 1 , the output of logic block1 keep
the state as before
---Object value of logic connection 1 after bus voltage recovery
The value of the parameter of logic connection1 initial by bus voltage
recovery .
Options: 0
1
0: Initialization logic connecttion1 value to 0.
1: Initialization logic connection1 value to 1.
---Result of logic block 1 inverted
setting this parameter to YES, the output of connection 1 will be
inverted.
Options: NO
YES
NO: Result of block not inverted.
YES: Result of block inverted.
--- logic connection2 enable
Enable this parameter, the logic connecton2 in
active state. The logic block 2 will no function by disable connect2
(“Con2”) , means the output of logic block 1 pass through “Out”
directly
Options: Disable
Enable
