Unpacking and Setting up 1
TANGO / TANGO XL – Operation 1–15
■
Removing the transparency arm trans-
port safeguard
Carefully remove the transport safeguard
which has been pushed onto the transpar-
ency arm.
■
Remove transport safeguard bar
Remove the transport safeguard bar at the
rear of the unit by pulling it out by hand.
■
Fit support
The scanner must not be assem-
bled without the support (safety
requirement)!
Using the 8 mm Allen wrench, fit the sup-
port to the scanner. This prevents it from
tipping over.
The support must not touch the floor after
assembly (important for scanner operation
– if necessary, adjust the unit’s feet, see
page 17 and onwards)!
