1 Unpacking and Setting up
1–18 Edition October 1998
The support, as well as 2 points on the base
of the unit must not touch the floor. At least
1 mm ground clearance must exist. This is
vital to ensure perfect scanner operation.
To adjust the feet, you need two wrenches,
sized 10 mm and 22 mm respectively.
You can adjust the foot using the 10 mm
wrench, and loosen and then lock the lock-
nut using the 22 mm wrench.
Once you have adjusted the feet, you can fit
the blanking plugs on the left and the right
at the back. Pay attention to the fitting posi-
tion. If a plug cannot easily be fitted, then
turn it around.
downwards
