Module management | Module management memory card screen
3
3.3
Module management memory card screen
Figure 7: Module management memory card screen
In the Module management memory card screen, you manage the modules that
are saved on the memory card inserted in the product.
The modules can be executed in the following ways:
The module is executed locally from the memory card. Executing a module
locally from the memory card is recommended for modules that are executed
only once or infrequently.
The module is transferred permanently to the flash memory of the product
and takes up one of the available module slots. Permanent transfer to the flash
memory is recommended for modules that are frequently used.
Tapping a module opens the Module action screen.
Further information: "Module action screen", Page 22
Opening the Module management memory card screen
Tap Module management in the Main menu
The Module management flash screen of the Module
management menu is opened
Swipe right to left
The Module management memory card screen is opened
3.4
Module action screen
Tapping a module in the Module management flash or Module management
memory card screen opens the Module action screen.
The available functions depend on the location where the module is saved (flash
memory or memory card) and on the status of the module (active or inactive).
22
HEIDENHAIN | PWT 101 Block Commutation Module | User's Manual | 07/2021
