Encoder diagnostics | Diagnosis
4.2.7
More menu
Use the More button to open the following screens of the Diagnosis menu:
Screen Function
Function settings The Function settings screen enables you to switch
on/off special encoder functions.
Display options for
count value
The Display options for count value screen enables
you to define display options for the count value.
Analysis information The Analysis information screen shows messages on
the signal analysis.
Display settings The Display settings screen enables you to change
the units of the values measured by the connected
encoder. The setting options vary depending on the
encoder.
The functions provided by the More menu depend on the respective
screens.
Open the More menu
Tap More
The More menu is opened
4
HEIDENHAIN | PWT 101 Block Commutation Module | User's Manual | 07/2021
