Encoder diagnostics | Diagnosis
4
Defining the count values
The Set the count value: parameter contains the starting value from which the
product starts counting.
Proceed as follows to specify the starting value:
Tap More
The More menu is opened
Tap Counter
The Display options for count value screen is opened
Tap the Off option of the Reset the count value with the
reference mark: parameter
Tap the On option of the Set the count value: parameter
Count value [steps] is displayed
Tap Count value [steps]
The product's on-screen keyboard is opened
Enter the desired starting value
Tap OK
Tap Back
The changed settings take effect
The Display options for count value screen is closed
