456 13 Tables and Overviews
13.1 General User Parameters
Configure tool table
(To omit from the
table: enter 0); Column
number in the tool
table for
MP7266.12
Tool comment – DOC: 0 to 31; column width: 16 characters
MP7266.13
Number of teeth – CUT.: 0 to 31; column width: 4 characters
MP7266.14
Tolerance for wear detection in tool length – LTOL: 0 to 31; column width: 6 characters
MP7266.15
Tolerance for wear detection in tool radius – RTOL: 0 to 31; column width: 6 characters
MP7266.16
Cutting direction – DIRECT.: 0 to 31; column width: 7 characters
MP7266.17
PLC status – PLC: 0 to 31; column width: 9 characters
MP7266.18
Offset of the tool in the tool axis in addition to MP6530 – TT:L-OFFS: 0 to 31
column width: 11 characters
MP7266.19
Offset of the tool between stylus center and tool center – TT:R-OFFS: 0 to 31
column width: 11 characters
MP7266.20
Tolerance for break detection in tool length – LBREAK: 0 to 31; column width: 6 characters
MP7266.21
Tolerance for break detection in tool radius – RBREAK: 0 to 31; column width: 6 characters
MP7266.22
Tooth length (Cycle 22) – LCUTS: 0 to 31; column width: 11 characters
MP7266.23
Maximum plunge angle (Cycle 22) – ANGLE.: 0 to 31; column width: 7 characters
MP7266.24
Tool type –TYP: 0 to 31; column width: 5 characters
MP7266.25
Tool material – TMAT: 0 to 31; column width: 16 characters
MP7266.26
Cutting data table – CDT: 0 to 31; column width: 16 characters
MP7266.27
PLC value – PLC-VAL: 0 to 31; column width: 11 characters
MP7266.28
Center misalignment in reference axis – CAL-OFF1: 0 to 31; column width: 11 characters
MP7266.29
Center misalignment in minor axis – CAL-OFF2: 0 to 31; column width: 11 characters
MP7266.30
Spindle angle for calibration – CALL-ANG: 0 to 31; column width: 11 characters
Configure pocket
tables; Column
number in the tool
table for
(To omit from the
table: enter 0)
MP7267.0
Tool number – T: 0 to 7
MP7267.1
Special tool – ST: 0 to 7
MP7267.2
Fixed pocket – F: 0 to 7
MP7267.3
Pocket locked – L: 0 to 7
MP7267.4
PLC status – PLC: 0 to 7
MP7267.5
Tool name from tool table – TNAME: 0 to 7
MP7267.6
Comment from tool table – DOC: 0 to 7
TNC displays, TNC editor
