HEIDENHAIN TNC 426, TNC 430 457
13.1 General User Parameters
Manual Operation
mode: Display of feed
rate
MP7270
Display feed rate F only if an axis direction button is pressed: 0
Display feed rate F even if no axis direction button is pressed (feed rate defined via soft key F or
feed rate of the “slowest” axis): 1
Decimal character MP7280
The decimal character is a comma: 0
The decimal character is a point: 1
Display mode MP7281.0 Programming and Editing operating mode
MP7281.1 Program run mode
Always display multiple line blocks completely: 0
Display multiline blocks completely if the multiline block is the active block: 1
Display multiline blocks completely if the multiline block is being edited: 2
Position display in the
tool axis
MP7285
Display is referenced to the tool datum: 0
Display in the tool axis is referenced to the
tool face: 1
Display step for the
spindle position
MP7289
0.1 °: 0
0.05 °: 1
0.01 °: 2
0.005 °: 3
0.001 °: 4
0.0005 °: 5
0.0001 °: 6
Display step MP7290.0 (X axis) to MP7290.8 (9th axis)
0.1 mm: 0
0.05 mm: 1
0.01 mm: 2
0.005 mm: 3
0.001 mm: 4
0.0005 mm: 5
0.0001 mm: 6
Disable datum setting MP7295
Do not disable datum setting: +0
Disable datum setting in the X axis: +1
Disable datum setting in the Y axis: +2
Disable datum setting in the Z axis: +4
Disable datum setting in the IVth axis: +8
Disable datum setting in the Vth axis: +16
Disable datum setting in the 6th axis: +32
Disable datum setting in the 7th axis: +64
Disable datum setting in the 8th axis: 128
Disable datum setting in the 9th axis: +256
Disable datum setting
with the orange axis
keys
MP7296
Do not disable datum setting: 0
Disable datum setting with the orange axis keys: 1
TNC displays, TNC editor
