38
2
Description
2.4
Symbols
2.4.1
Status symbols of the device or the dosage
The device is ready to dose, a dosage can be
started any time.
Touching this icon starts a dosage.
The selected mode of operation is shown in
the bottom right corner.
The rotor disk is being accelerated to the
rated speed.
A dosage is running.
By touching the symbol, the dosage could be
canceled.
After dispensing the product is sucked back.
By touching the symbol, the suck-back could
be canceled.
Error: No speed OK signal from the Rotor
spray received. Check the Rotor spray.
Reset the error by touching the symbol
.
Drive Error during dispensing.
A specific error number is displayed.
See section 7 for more details
Reset the error by touching the symbol
.
Product supply is not ready:
The reservoir is empty or vented, or a
reservoir pressure error is active.
Although the dosage has already ended, there
is still a start signal present.
