The odometer (1) shows accumulated
distance travelled.
The odometer displays from "0 to 999999" km
Tripmeter displays upto 999.9 km If the
tripmeter exceeds "999.9" km it will return
to "0.0" km automatically.
LCD PANEL
(a) Odometer/Tripmeter
When tripmeter is selected long press the reset
button (3) will reset tripmeter to zero.
The tripmeter (2) shows distance travelled
since trip meter was reset last time.
(1) Odometer (2) Tripmeter
(3) Reset button
2
3 1
The fuel gauge (1) is of a liquid crystal display
(LCD) type.
The approximate amount of fuel quantity
available in the fuel tank is indicated by the
number of segments (2) in the display.
(b) Fuel gauge
If all the segments are displayed it means fuel
quantity in the fuel tank is approximately 5.0
litres.
If only one segment (3) is displayed and start
blinking, this indicates that the fuel quantity is
low (approx 1 litre of fuel is available in fuel
tank). The fuel tank should be refilled as soon
as possible.
(1) Fuel gauge (2) Vertical bars
(3) One segment
CAUTION
!!
Please ensure the vehicle is not used
continuously when the fuel level indicator
reaches the one segment blinking. It will not only
result in the vehicle running out of fuel, it may
also cause serious damage to the fuel pump.
Please ensure fuel is filled up as soon as the fuel
level indicator reaches one segment blinking.
NOTE
To check the fuel level indication, the vehicle
should be on levelled surface and in stationary
condition.
3
2
1
