38
Installation is in the reverse order of removal.
•
Remove the six screws (1) from the inner
cover side.
•
Remove the front center cover (page 37).
Removal
Installation
(d) Front cover
(1) Screws
1
(3) Screws(2) Bolts
•
Remove the top and bottom screws (3).
•
Remove the four bolts (2) from the front
cover.
2
3
(4) Screws
•
Remove the screws (4) from the floor side
covers.
4
•
Remove the front cover and disconnect the
front turn signal lamp connectors (5).
(5) Front turn signal lamp connectors
5
Installation
Installation is in the reverse order of removal.
