PART FUNCTIONS
INSTRUMENTS AND INDICATORS
The indicators are in the speedometer panel
above the headlamp. The functions are as
below.
1
2 3
6
11 7
5
2 High beam indicator Light glows when headlamp is in Hi beam.
3 Speedometer Indicates riding speed.
5 Service reminder Displays when a service is due (page 17).
Shows the distance traveled since the last reset
6 Tripmeter
(page 16).
Sl. No.
Description
Function
Indicates approximate fuel quantity in the form of
digital segments. The fuel gauge segments will display
its maximum scale on the fuel gauge LCD panel once
when the ignition switch it turned "ON".
4 Fuel gauge
1 Side stand indicator
10
7 Odometer (page 16).Shows accumulated distance travelled
8 Turn signal indicator (R) Flashes when right turn signal switch is operated.
8
9
4
Light glows when the vehicle is parked on the side
stand. Side stand indicator glows continuously, if any
fault detected in the side stand system.
