HERO MAESTRO EDGE PROGRAMMED FI - Right Side View Component Identification

13
*Accessories and features shown may not be part of standard fitment.
(1) Exhaust muffler
(2) Hugger fender
(3) Oil level dipstick
(4) Pillion step
(5) Front fender
(6) Front turn signal lamp
(7) Position lamp
(10) Center compartment (inside)
(9) USB charger (inside)
(8) Front luggage hook
RIGHT SIDE VIEW
(12) Rear reflex reflector
(11) Licence plate lamp
(13) Rear fender
8
10
9
12
13
1 3 4
7
6
5
11
2
