HERO MAESTRO EDGE PROGRAMMED FI - Left Side View Component Identification

12
*Accessories and features shown may not be part of standard fitment.
(5) Side stand
(1) Front brake disc
(4) Side stand switch
(6) Main stand
(2) Caliper assembly
(3) CCB valve (inside)
(16) Front reflex reflector
(15) Headlamp
(13) Boot lamp (inside)
(12) Seat
(14) Rear luggage hook
LEFT SIDE VIEW
(8) Kick starter pedal
(11) Rear grip
(7) Pillion step
(9) Rear turn signal lamp
(10) Tail/stop lamp
15
16
12
14
13
11
9
10
6
7
3
4
5
1
8
2
