HERO MAESTRO EDGE PROGRAMMED FI - Vehicle Views and Component Identification; Top View Component Identification

TOP VIEW
VEHICLE VIEWS
(1) Programmed FI malfunction
indicator lamp (MIL)
(4) Turn signal switch
(5) Integrated brake lever
(7) Dimmer switch/Passing switch
(10) Speedometer
(3) Horn switch
(2) Turn signal indicator
(6) Rear view mirror
(8) Side stand indicator
(9) Hi beam indicator
(12) Service reminder
(11) Fuel gauge
(13) Tripmeter
(14) Front brake master cylinder (inside) /Reservoir
(15) Front brake lever
(17) Starter switch
(19) Ignition switch with steering lock, seat lock
and fuel lid opener
(16) Throttle grip
(18) Odometer
(20) Reset button
*Accessories and features shown may not be part of standard fitment.
11
15
17
18
19
20
16
5
6
1
3
2
4
11
8
12
10
7
9
13
14
