HERO MAESTRO EDGE PROGRAMMED FI - Essential Components: Ignition Switch; Ignition Switch Functions and Key Positions

IGNITION SWITCH
ESSENTIAL INDIVIDUAL COMPONENTS
The ignition switch (1) is on the right side
below the steering.
(1) Ignition switch
(2) Ignition key
(3) Steering lock position
(4) Seat open
(5) Fuel open
25
SEAT
OPEN
LOCK
PUSH
PUSH
FUEL
OPEN
IG
N
O
I
I
G
I
T
N
N
O
I
I
G
I
T
N
N
O
I
I
G
I
T
N
F
U
E
L
F
U
E
L
F
U
E
L
O
P
E
N
O
P
E
N
O
P
E
N
H
S
U
P
H
S
U
P
H
S
U
P
H
S
U
P
H
S
U
P
H
S
U
P
“SEAT OPEN”
Position
“ON” ( )
Position
“OFF” ( )
Position/Lock Open
“FUEL OPEN”
Position
“LOCK” Position
5
24 3
1
Key position
Function
Key removal
The engine can be started, position lamp, turn
signal lamps, horn, stop lamp, fuel gauge and
passing lamp can be operated. Programmed FI
malfunction indicator lamp (MIL) illuminates
Engine cannot be started and cannot be operated.
“LOCK”
Key cannot be removed
Key can be removed
Key can be removed
Seat can be opened by rotating the key
counterclockwise.
“SEAT OPEN”
Key can be removed
“FUEL OPEN”
Fuel tank lid can be opened by pushing the key
in and rotating it clockwise.
Key can be removed
Steering can be locked by pushing the key in
and rotating it counterclockwise.
“ON” ( )
“OFF” ( )
