64
(1) Battery band (2) Boot band clip
(3) (-)ve terminal (4) (+)ve terminal
•
Remove the battery (5).
(5) Battery
5
Battery installation
•
Reinstall in the reverse order of removal. Be
sure to connect the positive (+)ve terminal
first, then the negative (-)ve terminal.
Spare fuse (3) : 15A and 10A
FUSE REPLACEMENT
•
Check the bolts and other fasteners are
secured.
Main fuse (2) : 15A, 10A, 10A and 10A
The fuse box (1) is placed adjacent to the
battery which consist of main and spare fuses.
2
•
Remove the front center cover (page 37).
•
Always ensure the battery is fully charged
before installation.
•
Ensure the battery leads are properly
connected to the battery terminals during
installation.
Battery removal
•
Remove the battery band (1) from the boot
band clip (2) from both sides of the battery.
•
Disconnect the (-)ve terminal lead (3) from
the battery first, then disconnect the (+)ve
terminal lead (4).
3
1
4
