20
FUEL
The fuel tank is located under the seat.
To open the fuel filler cap (2), insert the
ignition key (3), push it in and turn the
ignition key to “FUEL OPEN” position (page
27). The fuel tank lid (1) will open as shown
in the picture. Remove the fuel filler cap by
turning it counterclockwise.
(a) Fuel tank
The fuel tank capacity is 5 litres (Minimum
fuel to be maintained above one segment
blinking of fuel level indicator).
Do not overfill the tank. There should be no
fuel (4) in the filler neck (5).
(1) Fuel tank lid (2) Fuel filler cap
(3) Ignition key
N
O
I
T
I
N
O
I
G
N
I
T
I
F
U
E
L
O
P
E
N
H
S
U
P
S
H
U
P
3 1
(4) Fuel (5) Filler neck
4
5
We recommend that you use unleaded petrol
because the muffler in the vehicle is fitted with
a catalytic convertor, it also produces lesser
deposits in engine and on spark plug, which
extends the life of exhaust system and other
components.
After refueling, be sure to tighten the fuel filler
cap firmly by turning it clockwise.
2
(5) Adjusting nut (6) Brake joint pin
(B) Cut-out seated
5
(A) Cut-out not seated
6
5
6
•
Check brake cable for kinks or signs of wear
that could cause sticking or failure.
Other checks:
•
Make sure the brake arm spring and
fasteners are in good condition.
NOTE
Apply the brake several times and check for
free wheel rotation after the brake lever is
released.
