16
A
4
(4) Integrated brake arm (5) First adjuster nut
(I) Decrease free play (ii) Increase free play
(i)
(ii)
Sheet Metal Wheel Version
5
NOTE
2. Turn the second adjuster nut (6) until a gap
is created between joint (7) and the slot on
the first side in integrated brake arm.
3. Check the free play of right lever.
Left hand front brake cable (B) on “I” side.
3. After ensuring the gap, turn the second
adjuster nut counterclockwise by half
rotation.
“F” & “I” is marked on integrated brake arm.
FREE PLAY : 10-20 mm
4. If the free play is more than 20 mm
further turn the adjuster nut to obtain
desired free play.
1. Push the integrated brake arm (4) by
hand in the direction as shown.
(6) Second adjuster nut
6
4
Sheet Metal Wheel Version
(6) Second adjuster nut
B
6
4
Cast Wheel Version
B
(i)
(ii)
(i)
(ii)
(I) Decrease free play (ii) Increase free play
(I) Decrease free play (ii) Increase free play
7
7
