If the drive chain or sprockets are excessively
worn or damaged, they should be replaced.
• Park the vehicle on its main stand with the
transmission in neutral and the ignition
switch in “OFF” position.
• Loosen the rear axle nut (1).
Adjustment
When operated at sustained high speeds or
under conditions of frequent rapid
acceleration, the chain may require more
frequent adjustments.
If the drive chain requires adjustment, follow
the procedures below:
Drive chain slack should be checked and
adjusted, if necessary at every 000 km.1
CAUTION
!!
Always replace the drive chain and sprockets
as a set. Otherwise the new part will wear
prematurely.
e
t
c
k
T
o
e
r
e
p
t
S
h
n
r
o
W
D
a
m
a
g
e
d
S
p
r
o
c
k
e
t
T
e
e
t
h
• Rotate the rear wheel slowly and inspect the
drive chain and sprockets for any of the
following conditions.
•
Loose pins
Drive chain
•
Damaged rollers
•
Dry or rusted links
•
Excessive wear
•
Improper adjustment
•
Damaged or missing O-rings.
Sprockets
•
Excessively worn teeth
•
Broken or damaged teeth.
If the drive chain has damaged rollers, loose
links or missing O-rings, replace it. If the
chain is dry or rusted, it should be lubricated.
Lubricate the chain if the links are kinked or
binding. If the problem is not solved after
lubrication, replace the chain.
•
Kinked or binding links
(3) Chain lock plate (4) Open end
3
4
