3.1.2.2. Body
Return mode
See Return Mode field in Section 3.1.2.3 Tail.
In Single Return mode, the measurements of each round of firing are stored in one block.
In Dual Return mode, the measurements of each round of firing are stored in two adjacent blocks, and the Azimuth fields of these two blocks
are the same.
Return Mode Odd-numbered block Even-numbered block Description
Last and Strongest Last return Strongest return If the last return is also the strongest, then the even-numbered
block stores the second strongest return.
Block 1 Block 2 Block 3 … Block 6
Azimuth 1 Azimuth 2 Azimuth 3 … Azimuth 6
Channel 1 Channel 1 Channel 1 … Channel 1
Channel 2 Channel 2 Channel 2 … Channel 2
… … … … …
Channel 64 Channel 64 Channel 64 … Channel 64
Each block in the body: 2 + 3 × 64 = 194 bytes
Field Byte(s) Description
Azimuth 2 Current reference angle of the azimuth
Unit: 0.01°
Pandar64
-34-
