Device overview
Fig. 3: ‘Lid closed’ indicator
Fig. 4: ‘Lid open’ indicator
Fig. 5: ‘Rotation’ indicator
Attention, general danger area.
Ensure you read the instructions for commissioning and operation and observe the safety instruc-
tions before using the device.
Biohazard warning.
Direction of rotation of the rotor.
The orientation of the arrow indicates the rotor's direction of rotation.
Symbol for the separate collection of electrical and electronic equipment, in accordance with
Directive 2012/19/EU (WEEE).
Use in European Union countries, Norway and Switzerland.
3.5
Operating and indicator elements
3.5.1 Control
Fig. 2: Control
3.5.2 Indicator elements
■
The indicator appears when the lid is closed.
■
If the ‘Lid closed’ and ‘Lid open’ indicators ash alternately, further
operation of the centrifuge is only possible after opening the lid once.
■
The indicator appears when the lid is open.
■
The indicator light rotates when the rotor is turning.
