Commissioning
Setting up the centrifuge
1
2 3
1 2
3
2
3
2
Fig. 14: Transport lock
1 Transport lock
2 Spacer sleeves
3 Screws
1.
Tilt the device on the back of the device.
2.
Unscrew 3 screws ( 3 ) with spacer sleeves ( 2 ).
3.
Remove 3 transport locks ( 1 ) and store them safely.
4.
Keep the screws, spacer sleeves and transport lock in a safe place.
5.3
Setting up and connecting the centrifuge
WARNING
Risk of injury due to failing to maintain a
sufcient distance to
the centrifuge.
− As per EN/IEC 61010-2-020, no persons, hazardous
materials or objects may be present within a safety zone
of 300mm around the centrifuge during a centrifugation
run.
−
A distance of 300mm from the ventilation slots and ven-
tilation openings of the centrifuge must be maintained.
CAUTION
Risk of crushing and damage to the device due to it falling
down because of vibration-induced position alterations.
− Place the device on a stable and level surface.
− Select the installation surface dependent on the weight
of the device.
