8 Load profile
8.1 Load profile capacity
Load Profile
Default application
Max. capture items
Profile total bytes
Load Profile 1 Hourly Data(energy) 60 228kbyte
Load Profile 2
Hourly Data(Instantaneous)
60
892kbyte
Load Profile 9 Daily Billing Data 60 32kbyte
 The period can be setting from 1-1440mins, when you choose 0, means no need for this
profile. Common period are 15 or 30 minutes
 When you change the objects or period in profile, the data will be erase.
 The average, minimum and maximum value of the instantaneous data can only be
configuring in only Load profile 2, consult the engineer for details.
8.2 Capture object list
Object Number of bytes
Clock
14
Load profile status word
2
Import active energy
5
Export active energy 5
Combined active energy
5
Net active energy 5
Import reactive energy
5
Export reactive energy
5
Reactive energy in QI
5
Reactive energy in QII 5
Reactive energy in QIII
5
Reactive energy in QIV 5
Import apparent energy
5
Export apparent energy
5
Import active energy per tariff
5
Export active energy per tariff 5
Combined active energy per tariff
5
