HEXING HXE110 - Appearance

User manual for single-phase meter
2
2 Appearance
1. Communication module
6. LCD window
11. Display button
2. Communication module seal 7. Terminal cover 12. Sealable button
3. Active pulse LED 8. Terminal Block 13. Optical port
4. Alarm LED
9. Terminal cover seal
14. Meter cover seals
5. Reactive pulse LED 10. Auxiliary interface
2
3
4
6
7
14
14
2
5
8
9
10
11
12
13
1
