Annex A Communication and Display OBIS
Display items
Display OBIS
code
Display format
Energy
Active energy import (+A)
1.8.0
xxxxxx.xx kWh
Active energy import (+A) rate X
1.8.X
xxxxxx.xx kWh
Active energy export (-A)
2.8.0
xxxxxx.xx kWh
Active energy export (-A) rate X 2.8.X xxxxxx.xx kWh
Reactive energy import (+R)
3.8.0
xxxxxx.xx kWh
Reactive energy import (+R) rate X 3.8.X xxxxxx.xx kWh
Reactive energy export (-R)
4.8.0
xxxxxx.xx kvarh
Reactive energy export (-R) rate X
4.8.X
xxxxxx.xx kvarh
Reactive energy of QI
5.8.0
xxxxxx.xx kvarh
Reactive energy of QI rate X 5.8.X xxxxxx.xx kvarh
Reactive energy of QII
6.8.0
xxxxxx.xx kvarh
Reactive energy of QII rate X 6.8.X xxxxxx.xx kvarh
Reactive energy of QIII
7.8.0
xxxxxx.xx kvarh
Reactive energy of QIII rate X
7.8.X
xxxxxx.xx kvarh
Reactive energy of QIV
8.8.0
xxxxxx.xx kvarh
Reactive energy of QIV rate X 8.8.X xxxxxx.xx kvarh
Apparent energy import
9.8.0
xxxxxx.xx kVAh
Apparent energy import rate X 9.8.X xxxxxx.xx kVAh
Apparent energy export
10.8.0
xxxxxx.xx kVAh
Apparent energy export rate X
10.8.X
xxxxxx.xx kVAh
Combined active energy
15.8.0
xxxxxx.xx kWh
Combined active energy rate X 15.8.X xxxxxx.xx kWh
Net active energy
16.8.0
xxxxxx.xx kWh
Net active energy rate X 16.8.X xxxxxx.xx kWh
Instantaneous
Instantaneous voltage on phase A
32.7.0
xxx.xx V
Instantaneous current on phase A
31.7.0
xxx.xx A
Instantaneous net frequency 14.7.0 xx.xx Hz
Instantaneous active import power (+A)
1.7.0
xx.xx kW
Instantaneous active export power (-A) 2.7.0 xx.xx kW
Instantaneous reactive import power (+R)
3.7.0
xx.xx kvar
Instantaneous reactive export power (-R)
4.7.0
xx.xx kvar
